Descripción técnica
Cuadro
Cuadro:
Twostroke 01 Premium Carbon with Tuned Compliance Concept XC | Fully Guided Internal Cable Routing | Post Mount Disc | 12 x 148mm Boost Thru-Axle
Horquilla:
Suspensión
Suspensión Delantera:
RockShox Reba RL
Cockpit
Potencia:
#spec_stem
Manillar:
BMC MFB 01 Carbon | 760mm
Puños:
Seat
Tija de Sillín:
Twostroke 01 Premium Carbon D-Shaped Seatpost | 0mm Offsett
Sillín:
Fizik Antares R7
Transmisión
Platos y Bielas:
SRAM GX Eagle
Platos:
34T
Potenciómetro:
Cassette:
SRAM GX Eagle
Tamaño del cassette:
10-52T
Cadena:
SRAM GX Eagle
Desviador Delantero:
Cambio Trasero:
SRAM GX Eagle
Manetas de Cambio:
SRAM GX Eagle
Marchas:
1 x 12
Pedalier:
PF92 Bottom Bracket
Frenos
Pinzas de Freno:
SRAM Level TL
Discos:
SRAM Centerline
Tamaño del disco:
160 / 160 S-M | 180 / 160 L-XL
Ruedas
Llantas:
DT Swiss X 1900 | 25mm Inner Width
Bujes:
DT Swiss 370 Disc
Neumáticos:
Vittoria Barzo | 2.25"
Información adicional
Paso de rueda:
58mm
Peso sin pedales:
Clasificación ASTM:
Level 3
Límite de peso del sistema:
110kg
| Size | S | M | L | XL |
|---|---|---|---|---|
| Rider Height | 162-172 | 170-180 | 178-188 | >188 |
| Reach | 422.5 | 445 | 465 | 485 |
| Stack | 588 | 598 | 608 | 623 |
| Bar Rise | 4 | 4 | 4 | 4 |
| Bar Sweep | 8 | 8 | 8 | 8 |
| Bar Width | 760 | 760 | 760 | 760 |
| BB Drop | 64 | 64 | 64 | 64 |
| Crank Length | 170 | 175 | 175 | 175 |
| Fork Length | 505 | 505 | 505 | 505 |
| Fork Rake | 44 | 44 | 44 | 44 |
| Front Center | 696 | 715 | 741 | 767 |
| Head Tube | 87 | 93.5 | 106 | 122.5 |
| Head Tube Angle | 67 | 67 | 67 | 67 |
| Rear Center | 425 | 425 | 425 | 425 |
| Seat Angle | 75 | 75 | 75 | 75 |
| Seat Tube | 410 | 440 | 480 | 510 |
| Seatpost Length | 380 | 430 | 430 | 430 |
| Standover Height | 725 | 730 | 735 | 750 |
| Stem Angle | -5 | -5 | -5 | -5 |
| Stem Length | 50 | 60 | 60 | 70 |
| Top Tube | 597 | 618 | 638 | 658 |
| Trail | 109 | 109 | 109 | 109 |
| Wheelbase | 1112.5 | 1135 | 1161 | 1185 |
